Direct Burial Category 5e UTP Cable
Overview
- For direct burial applications.
- Meets or exceeds requirements of ANSI/TIA-568.2-D Category 5e and ISO 11801 2nd Edition Class D channel standards.
Key Features
- Meets or exceeds requirements of ANSI/TIA-568.2-D and IEC 61156-5 Category 5e component standards.
- Third party tested to Category 5e channel compliance.
- Meets requirements of IEEE 802.3af and IEEE 802.3at for PoE applications.
- Descending length cable markings enable easy identification of remaining cable which reduces installation time and cable scrap.
- UL Verified.
Specifications
- Impedance: 1-100MHz 100±15(Ohms).
- Rated Temperature: 75℃.
- DC Resistance Unbalance(%): Max 2.5.
- DC Resistance 20℃: 9.5(Ohms/100m).
- Pair-to-Ground Capacitance Unbalance: 330(pF/100M).
- Insulation Resistance: >5000MΩ*Km.
- Dielectric strength: DC 2500V 2S.
